Products Description
High Precision Machining,±0.005 mm Positioning Accuracy:Deliver stable precision and superior surface finish for molds, automotive parts and high-value metal components.
BT40 High-Speed Spindle,8000 RPM Powerful Cutting Performance :BT40 spindle provides stable cutting, faster material removal and consistent machining on steel, aluminum and stainless steel.
Heavy-Duty Machine Structure,HT300 Cast Iron Construction : Rigid machine structure minimizes vibration and maintains machining accuracy during long-term continuous production.
High-Efficiency Automatic Tool Changer,Optional 24 Tool ATC: Automatic tool changing shortens setup time and increases productivity for continuous batch machining.
Large Travel for Bigger Parts,1000 × 600 × 600 mm Working Travel :Large machining envelope easily handles molds, plates, housings, flanges and complex industrial components.
Wide Material Compatibility,Machine More Materials with One VMC : Suitable for aluminum, carbon steel, alloy steel, stainless steel, cast iron and engineering plastics.
Factory Direct OEM Manufacturing,Professional CNC Machine Manufacturer : OEM & ODM support, fast production, strict quality control and global export experience for distributors and industrial buyers.
Global Technical Support,Global Technical Support:Professional installation guidance, remote technical support, spare parts supply and fast response ensure worry-free operation.
system
Product Parameter
|
SPECIFICATIONS |
Units |
VMC850 |
VMC860 |
VMC1050 |
|
Table size |
mm |
1000*500 |
1000*550 |
1000*500 |
|
X axis travel |
mm |
800 |
850 |
1000 |
|
Y axis travel |
mm |
500 |
600 |
500 |
|
Z axis travel |
mm |
500 |
600 |
500 |
|
Max. worktable load |
kg |
500 |
600 |
500 |
|
T slot(number-width*pitch) |
- |
5-18*90 |
5-18*90 |
5-18*90 |
|
Max. spindle speed |
rpm |
8000 |
8000 |
8000 |
|
Spindle taper |
mm |
BT40 |
BT40 |
BT40 |
|
Main motor power |
kw |
7.5 |
7.5 |
7.5 |
|
X/Y/Z rapid traverse speed |
m/min |
24/24/20 |
24/24/20 |
24/24/20 |
|
Cutting feed speed |
mm/min |
1-8000 |
1-8000 |
1-8000 |
|
Guide rail type |
- |
Linear rail |
Linear rail |
Linear rail |
|
Distance from spindle axis to column surface |
mm |
525 |
590 |
525 |
|
Distance between spindle nose and table surface |
mm |
130-630 |
130-660 |
130-630 |
|
Positioning accuracy |
mm |
0.0075 |
0.0075 |
0.0075 |
|
Repeat positioning accuracy |
mm |
0.005 |
0.005 |
0.005 |
|
Tool magazine |
- |
Arm 24 |
Arm 24 |
Arm 24 |
|
Max. tool diameter |
mm |
78/120 |
78/120 |
78/120 |
|
Max. tool weight |
kg |
8 |
8 |
8 |
|
Machine weight |
kg |
5000 |
5600 |
5200 |
|
Overall dimension(L*W*H) |
mm |
2600*2300*2800 |
2900*2400*2800 |
3200*2400*2800 |
Factory
FAQ
20,000+ m² Manufacturing Facility
Modern production workshop with 180+ skilled employees for efficient manufacturing and stable product quality.
24+ Quality Inspection Procedures
Every machine is thoroughly tested before shipment to ensure precision, reliability and consistent performance.
20+ Years of CNC Manufacturing Experience
Professional CNC machine manufacturer with extensive industry expertise and global export experience.
24/7 Online Technical Support
Fast response from our experienced engineers with online guidance and technical assistance worldwide.
Exported to 80+ Countries
Trusted by customers across Europe, America, Asia, Africa and the Middle East.
Global CNC Brand Compatibility
Supports FANUC, Siemens, Mitsubishi, SYNTEC, GSK and LNC control systems.
OEM & ODM Customization
Customized machine configuration, voltage, color, logo and CNC system based on customer requirements.
18-Month Warranty
Long-term spare parts supply and professional after-sales service for worry-free operation.
