Products Description
Structural Features:
a. The machine tool is mechanically, electrically, and hydraulically controlled, primarily by manual operation.
b. The workpiece is driven by a headstock motor via a special fixture, with mechanical synchronous drive for manual feed grinding.
c. The grinding wheel head moves longitudinally, either manually or mechanically. In mechanical mode, the worktable can only move rapidly in points for gear shifting or adjustment.
d. The workpiece, grinding wheel, worktable, cooling pump, and oil pump are all driven by individual motors.
e. The grinding wheel head uses a hydraulic and electrical interlocking mechanism, ensuring safety during adjustments or grinding to prevent operational errors. The grinding wheel head has a reliable protective cover.
f. The head and tailstock spindles are hydrostatic spindles with high rigidity and precision.
Accessories of Crankshaft Grinding Machine Standard accessories:
jaw chucks
wheel dresser
wheel balancing arbor
leveing wedge
driving dog
vertical aligning stand
horizontal aligning stand
wheel balancing stand hanging measuring device steady rest centering device
grinding wheel
Optional accessories:
Polisher
Steady rest
Hanging measuring device
Diamond dresser
Digital display device
|
Specifications |
Unit |
MQ8260A |
MQ8260B |
MQ8260C |
MQ8240A |
|
|
Max work diameter*Max work length |
mm |
580*1600 |
580*1800 |
580*2000 |
400*750 |
|
|
Capacity |
Max swing over table |
mm |
580 |
580 |
580 |
400 |
|
Workdiameter ground with steady rest |
mm |
30-100 |
30-100 |
50-120 |
20-110 |
|
|
Throw of crankshaft |
mm |
110 |
110 |
120 |
60 |
|
|
Max.work length ground :in 3-jaw chuck |
mm |
1400 |
1400 |
1800 |
630 |
|
|
Between centers |
mm |
1600 |
1600 |
2000 |
750 |
|
|
Max.work weight |
kg |
120 |
120 |
150 |
30 |
|
|
Head-stock |
Centre height |
mm |
300 |
300 |
300 |
210 |
|
Work speed |
rpm |
25/45/95 |
25/45/95 |
25/45/65/100 |
40/80 |
|
|
Wheel head |
Max cross movement |
mm |
185 |
185 |
185 |
150 |
|
Wheelhead rapid approach&withdrawal |
mm |
100 |
100 |
100 |
100 |
|
|
Wheelhead feed per turn of cross feed handwheel |
mm |
1 |
1 |
1 |
1 |
|
|
Wheel feed per grad of cross feed handwheel |
mm |
0.005 |
0.005 |
0.005 |
0.005 |
|
|
Grinding wheel |
Wheel spindle speed |
rpm |
740/890 |
740/890 |
740/890 |
890 |
|
Wheel peripheral speed |
m/sec |
25.6-35 |
25.6-35 |
25.6-35 |
25.6-30 |
|
|
Wheel size |
mm |
900*32*305 |
900*32*305 |
900*32*305 |
750*32*305 |
|
|
Table |
Table traverse per turn of handwheel:coarst |
mm |
5.88 |
5.88 |
5.88 |
14 |
|
Table traverse per turn of handwheel:fine |
mm |
1.68 |
1.68 |
1.68 |
1.55 |
|
|
Table swivel(taper 18/100) |
|
5° |
5° |
5° |
5° |
|
|
Table swivel pergrad of scal(taper1:50) |
|
10' |
10' |
10' |
10' |
|
|
Overall capacity of motor |
kw |
9.82 |
9.82 |
11.12 |
6.92 |
|
|
Overall dimensions(L*W*H) |
mm |
4166*2037*1584 |
4166*2037*1584 |
4900*2037*1584 |
2860*1960*1650 |
|
|
Weight |
Kg |
6000 |
6200 |
7000 |
4800 |
|
